SO-525 DIRECT SHEAR TEST SET, ASTM D-3080 / AASHTO T-236
For determining shearing resistance of soil sample
Consist of :
SO-526 Loading Machine
Consist of :
SO-526.1 Frame; welded steel frame hand operated ( 1 pc)
SO-526.2 Loading Hanger ( 1 pc)
Machine steel, galvanized, supplied without load
SO-527 Shear Box ( 1 set)
Cast alumunium box, 63.5 mm sample dia porous stone, loading capacity.
SO-523 Loads; slotted, machine steel, galvanized.
Consist of :
SO-523.1 Load, 3167 gr weight ( 2 pcs)
SO-523.2 Load, 6334 gr weight ( 1 pc)
SO-524 Sample Tube ( 1 set)
Machine steel, 63.5 mm dia., galvanized, with extruder.
GE-101/ 1 Proving Ring, 100 kg capacity ( 1 pc)
GE-135 Dial Indicator, Range 10mm x 0.01mm ( 1 pc)
GE-136 Dial Indicator, Range 20mm x 0.01mm ( 1 pc)
GE-840 Wire Saw, 10 cm length approx ( 1 pc)
Dimension ( l x w x h) : 130 x 50 x 130 cm
Gross Weight : 125 kg
