STANDARD PENETRATION TEST / SPT ( SO-130 A) ; ASTM D-1586 - AASHTO T-206
SO-130 A STANDARD PENETRATION TEST / SPT; ASTM D-1586 - AASHTO T-206
For driving a split barrel sampler to obtain a representative soil sample and
measure the soil resistance to penetration.
Consist of :
SO-131 Split Barrel Sampler ( 1 pc)
Hardened machined steel, 1 3/ 8 " I.d; 18 " length.
SO-132 Sampling Rod; steel pipe, 1.5 m length. ( 20 pcs)
SO-133 Drive weight Assembly
Consist of :
SO-133.1 Hammer; steel, 63.5 kg weight ( 1 pc)
SO-133.2 Anvil; machine steel ( 1 pc)
SO-133.3 Guide Rod ( steel, 76.2 cm drop height ( 1 pc)
SO-134 Tripod Assembly
Consist of :
SO-134.1 Tripod Stand; steel pipe ( 1 pc)
SO-134.2 Pulley; 20 cm ciameter ( 1 pc)
SO-134.3 Rope; 3/ 4 " diameter x 15 mtr ( 1 rol)
SO-137 Vertical Guide; machine steel ( 1 pc)
GE-739 Pipe Wrench; 24 " length ( 2 pcs)
Dimension ( l x w x h) : 330 x 60 x 60 cm
Gross Weight : 445 kg
